db Drive WDX 8 G2.4 - 1500 Watt Max Power Dual 4 Ohm Car Subwoofer
$299.95
In Stock
Sold out
CODE:
Categories: 8 Inch Subwoofers, 8", Best Sellers!, Car Speakers, SUBWOOFERS, SUBWOOFERS
100% ORIGINAL AND QUALITY
24 MONTHS GUARANTEE
- Description
- Shipping and Refund
db Drive WDX 8 G2.4 - 1500 Watt Max Power Dual 4 Ohm Car Subwoofer
Watch our Video Review on Youtube ⬇️
Our engineers at DB Drive have designed this subwoofer from the ground up to shake the ground up. The double stitched foam surround along with the die-cast aluminum vented basket allow for maximum excursion while the protective magnet cover gives the woofer a rugged yet stylish appearance.
-
- 2.5″ Anodized aluminum high temperature voice coil
- Non-Pressed paper cone
- Double stitched foam surround
- Dual poly-cotton dampeners
- Die-cast aluminum vented basket
- Rubber gasket trim ring
- Large gauge compression terminals
- Protective magnet cover
Specifications
| Outside Diameter (A) | 8.76″ (222.50mm) |
| Cutout Diameter (B) | 7.20″ (182.88mm) |
| Mounting Depth (C) | 5.33″ (135.38mm) |
| GENERAL SPECIFICATIONS | |
|---|---|
| Structure | 8″ (20.3cm) Woofer |
| Dynamic Power Handling | 1500 Watts |
| Nominal Power Handling | 750 Watts |
| Impedance | Dual 4Ω Voice Coil |
| PARAMETERS | |
|---|---|
| Resonant Frequency (fs) | 55.71Hz |
| D.C. Voice Coil Resistance (Re) | 3.2 x 3.2Ω |
| Mechanical Quality Factor (Qms) | 6.234 |
| Electrical Quality Factor (Qes) | 0.757 |
| Total Quality Factor (Qts) | 0.675 |
| Equivalent Air Volume to Cms (Vas) | 3.519 L |
| Mass of Diaphragm/Coil (Mms) | 150.516 g |
| Force Factor (Bl) | 10.550 |
| Sound Pressure Level (SPL) | 80.9 dB |
RECOMMENDED ENCLOSURES
| Woofer Cut-out | 7.32″ (186mm) |
| Mounting Depth | 6.30″ (160mm) |
| Sealed Box | 0.9 ft3 (24.48L) |
| Vented Box | 1.13 ft3 (31.99L) |
| ? Vent Area | 10 in2 (64.51 cm2) |
| ? Vent Length | 22″ (55.88 cm) |
| ? Tuning | 33Hz |
| Dynamic Power | 1500 Watts |
| Nominal Power | 750 Watts |
