db drive NEOM1 - Marine Mono Full Range Amplifier
- 2 Channel Class D Full Range Technology
- 2Ω Stereo load Capability
- Audiophile Grade Nickel Plated RCA connectors
- Variable 12db High-Pass or Low-pass crossover filters
- Bridgable outputs @ 4Ω load
- Marine Grade Conformal Coated Double Sided PCB
- Compatible with any 4/2Ω Loudspeaker
| GENERAL SPECIFICATIONS | |
|---|---|
| Rated Power @ 14.4 Volts | |
| Dynamic Power Handling | 2 x 125 Watts @ 4Ω |
| 1 x 500 Watts @ 4Ω Bridged
2 x 250 Watts @ 2Ω |
| PARAMETERS | |
|---|---|
| THD (100Hz @ 1Ω) | 0.04% |
| Bandwidth (-3 dB) | 18Hz – 22KHz |
| Damping Factor (1KHz @ 4Ω) | 100 |
| S/N ratio (as weighted @ 1 Volt) | 99db |
| Input Sensitivity | 0.20V – 6.0V RMS |
| Minimum Load Impedance | 2Ω |
| Low-Pass Filter Range | 50Hz – 300Hz |
| Sub-Sonic Filter Range | 15Hz – 300Hz |
